Gearbox Oil in speedometer

Postby rsi16vtcam » Tue Jun 21, 2011 12:20 pm

HI The gearbox oil is coming thru the speedo cable into the speedometer what can I do to fix this or what can I check for. Has anybody experienced this.
2005 RunX 160 RS
1987 Conquest RSI 16V Twincam
1979 Corolla 1.6 deluxe 5 speed

User avatar
superCboy
Regular
Posts: 1684
Joined: Thu Nov 15, 2007 6:12 pm
Location: Cape Town

Re: Gearbox Oil in speedometer

Postby superCboy » Tue Jun 21, 2011 1:01 pm

I think there is one little "10 " spanner bolt holding it in place. remove the bolt and pull out the speedo unit. I assume the O ring on it is done.
Daily: 3rd Gen 3SGE sw20 MR2, 90 T-Top, Bone stock
Track Project:4AGZE,Sc14 charger 93 "Bubble shape" Corrola
Future project? TWINCHARGE
The Best of both worlds!


NUR 11448
Internet Racer
Posts: 161
Joined: Sat May 24, 2008 4:32 pm

Re: Gearbox Oil in speedometer

Postby NUR 11448 » Tue Jun 21, 2011 1:11 pm

superCboy wrote:I think there is one little "10 " spanner bolt holding it in place. remove the bolt and pull out the speedo unit. I assume the O ring on it is done.


just a quick question, if the gearbox oil is empty, would the speedometer stop working?

Thanks
Prevern

Current
2001 Toyota Corolla Rxi
1990 Toyota Corolla 1.6
Ex
1992 Toyota Corolla Gli Twincam 16v

rsi16vtcam
Newbie
Posts: 69
Joined: Thu Aug 03, 2006 7:15 am
Location: Midrand

Re: Gearbox Oil in speedometer

Postby rsi16vtcam » Tue Jun 21, 2011 1:15 pm

no if the oil is low the speedo will still work as it is driven by a gear in the gearbox not the oil level. If speedo stops working the cable inside must have broken off.
2005 RunX 160 RS
1987 Conquest RSI 16V Twincam
1979 Corolla 1.6 deluxe 5 speed

Steve
Road Kill
Posts: 913
Joined: Thu Mar 26, 2009 8:29 pm
Location: Woes Rand

Re: Gearbox Oil in speedometer

Postby Steve » Wed Jun 22, 2011 5:15 pm

:shock: :shock: I had to read the thread topic twice just to believe it :shock:

Good luck sorting it out :)
'97 RSI 5-speed in red.
Stock.

370 000km - 15/07/14
360 000km - 05/10/13
350 000km - 02/02/13
340 000km - 24/04/12.
333 333km - 11/11/11.
330 000km - 29/08/11.
320 000km - 05/12/10.
220 000km (and still going) on one clutch.
Legend.

User avatar
LowRSI
Guru
Posts: 2320
Joined: Mon Jun 29, 2009 4:06 pm
Location: JHB Roodepoort

Re: Gearbox Oil in speedometer

Postby LowRSI » Thu Jun 23, 2011 6:50 am

reason for this can be overfilled gearbox, or the seal/oring in drive unit has failed, then the cable turning in the sheath will act like a screw pump, taking the oil up to the speedo.

and yes if the gearbox has no oil the speedo will stop working, primarily because the box will seize in no time and the car will stand :P
